ATR 4500
ATR 4500
Surface-mounted thermostat as room controller 5...30 C, AC 230V, triac, 6 therm. Actuators switchable (18 W), automatic
| Article number | 567195457600 |
|---|---|
| Contact | Heating/cooling changeover |
| Voltage | AC 230 V / 50 Hz |
| Switching current | Triac output max. 2 A |
| Colour | active white (similar to RAL 9016) |
| Temperature range | |
| Measurements | 86 x 86 x 21 mm |
| Technology | Electronic |
| Temperaturedrop | |
| Surface | glossy |
| Control procedure | PWM / ON/OFF (adjustable) |
| Display | Yes |
| Programmable | No |
| Remote sensor | |
| Switch | |
| LED |
Digital surface-mounted room controller with very low installation height of just 21 mm for wall mounting. Active white glossy. With triac output. Suitable for water-led heating systems. Very large black display with backlighting. Text display for self-explanatory operation. Universal input for heating/cooling switchover, setback or presence selectable. Short-term timer (eco/party mode) for changing the temperature by the hour. Frost protection. Temperature display can be adapted to local conditions. Unauthorized access protection. PWM or 2-point control method. Surface mounting or directly on flush-mounted box with horizontal/vertical fixing holes.
Window open detection (can be set in the menu)
ATR 4500-EasyLink
EasyLink 868 Wireless Individual Room Control System (868 MHz) Digital battery-powered wireless room thermostat for heating and cooling applications
| Article number | 563600097600 |
|---|---|
| Contact | Heating/Cooling via RF signal from actuator |
| Voltage | 3 VDC: 2x AAA |
| Switching current | |
| Colour | active white (similar to RAL 9016) |
| Temperature range | 5 … 30°C |
| Measurements | 86 x 86 x 21 mm |
| Technology | |
| Temperaturedrop | |
| Surface | glossy |
| Control procedure | PWM or ON/OFF selectable |
| Display | Yes |
| Programmable | Yes |
| Remote sensor | |
| Switch | |
| LED |
Wireless thermostat as part of the EasyLink 868 system. Communication between the room thermostat and actuator is wireless via the 868 MHz frequency band, a proven industry standard known for reliable performance in residential and commercial applications. No wall chasing or additional wiring is required, making the EasyLink 868 system ideal for renovation, retrofit, and modernization projects. The ATR 4500-EasyLink features an ultra-slim design and is battery-powered (2 × AAA batteries, up to 2 years battery life). It enables simple and fast zone management via the integrated display. Automatic heating/cooling changeover is supported. Control modes include PWM and On/Off (2-point) control. Installation options include wall mounting with or without a wall bracket, or placement on a desktop stand.
Timer for Eco and Party mode, wireless RF output, wireless range up to 150 m line-of-sight (typically through 1 ceiling or 3 walls), wireless communication via 868 MHz / LoRa, selectable PWM cycle time 5...20 min, selectable hysteresis 0.1 K or 0.5 K, frost protection at 5 °C, adjustable valve protection function (duration and activation time), EN 50559 temperature limitation 5 min / 60 min when used with EV 1K-EasyLink actuator, open-window detection with adjustable temperature drop threshold and detection time, parameterization and RF commissioning via installation menu, user menu and RF commissioning directly via thermostat display.
