ATR 4500
Surface-mounted thermostat as room controller 5...30 C, AC 230V, triac, 6 therm. Actuators switchable (18 W), automatic
| Article number | 567195457600 |
|---|---|
| Contact | Heating/cooling changeover |
| Voltage | AC 230 V / 50 Hz |
| Switching current | Triac output max. 2 A |
| Colour | active white (similar to RAL 9016) |
| Temperature range | |
| Measurements | 86 x 86 x 21 mm |
| Technology | Electronic |
| Temperaturedrop | |
| Surface | glossy |
| Control procedure | PWM / ON/OFF (adjustable) |
| Display | Yes |
| Programmable | No |
| Remote sensor | |
| Switch | |
| LED |
Digital surface-mounted room controller with very low installation height of just 21 mm for wall mounting. Active white glossy. With triac output. Suitable for water-led heating systems. Very large black display with backlighting. Text display for self-explanatory operation. Universal input for heating/cooling switchover, setback or presence selectable. Short-term timer (eco/party mode) for changing the temperature by the hour. Frost protection. Temperature display can be adapted to local conditions. Unauthorized access protection. PWM or 2-point control method. Surface mounting or directly on flush-mounted box with horizontal/vertical fixing holes.
Window open detection (can be set in the menu)
